Description
FR2F1700 – 1700 mAh Receiver LiFe Battery
Lithium Ferrite Battery for receivers that correspond to 7.4V as the power-supply voltage, do not use with other devices. (EBA0145) NOTE: This is for RECEIVER use ONLY.
IMPORTANT USAGE NOTE:
When using five or more high torque servos of 20 kg/cm or greater, distribute the servo power by using the S/Bus hub with cable for remote battery pack use (NOT INCLUDED).
TYPE:
Rechargeable LiFeP04 Polymer Battery.
NOMINAL OUTPUT VOLTAGE:
DC 6.6 V
NOMINAL CAPACITY:
1700 mAh
CHARGING/DISCHARGING COUNT:
Approximately 500 Cycles
(Variable depending on the operating/usage conditions)
DIMENSIONS:
~30 mm x ~90 mm x ~20 mm
WEIGHT:
~83 g
CHARGING TEMPERATURE:
0 to 45° C
DISCHARGING TEMPERATURE:
-20 to 60° C
STORAGE TEMPERATURE:
-20 to 25° C
CHARGER (NOT INCLUDED):
LBC-4E5
