Find the Best Receiver for You

Make sure you pick the right receiver for your RC needs by looking through the features of Futaba's air and surface receivers. Sideways scrolling may be required to view certain aspects of the tables.

Model Ports PWM Outputs S.Bus Ports S.Bus2 Ports Channel Mode Settings FASST Telemetry S-FHSS High Speed HV Connector Range
R2004GF 5 4 0 0 No No No FHSS No Yes J (STND) Parkflyer
R2006GS 7 6 0 0 No No No Yes Yes Yes J (STND) Full-range
R2008SB 8 8 1 0 No No No Yes Yes Yes J (STND) Full-range
R2106GF 6 6 0 0 No No No Yes Yes Yes J (STND) Parkflyer
R2001SB 2 1 1 0 No No No Yes Yes Yes J (STND) Full-range
R3001SB 2 1 1 1 Yes - S.Bus, 3 Ch. No Yes (T-FHSS) No Yes Yes J (STND) Full-range
R3004SB 5 4 0 1 No No Yes (T-FHSS) No Yes Yes J (STND) Full-range
R3006SB 7 6 1 1 Yes - S.Bus, 6 Ch. No Yes (T-FHSS) No Yes Yes J (STND) Full-range
R3106GF 7 6 0 0 No No No No No Yes J (STND) Full-range
R3008SB 9 8 1 1 Yes - 4 Modes No Yes (T-FHSS) No Yes Yes J (STND) Full-range
R6004FF 6 4 0 0 No Yes No No No No J (STND) Indoor
R6008HS 9 8 0 0 Yes - Hi-Speed/Normal Yes No No Yes No J (STND) Full-range
R6014HS 16 14 0 0 Yes - Hi-Speed/Normal Yes No No Yes No J (STND) Full-range
R6106HF 6 6 0 0 Yes - Hi-Speed/Normal Yes No No Yes Yes J (STND) Parkflyer
R6106HFC 6 6 0 0 Yes - Hi-Speed/Normal Yes No No No Yes J (STND) Mid-range
R616FFM 7 6 0 0 No Yes No No No No Micro Indoor or Parkflyer
R617FS 7 7 0 0 No Yes No No No No J (STND) Full-range
R6202SBW 4 2 2 0 Yes - Hi-Speed/Normal Yes No No Yes Yes J (STND) Full-range
R6203SB 4 3 1 0 Yes - Hi-Speed/Normal Yes No No Yes Yes J (STND) Full-range
R6203SBE 4 3 1 0 Yes - Hi-Speed/Normal Yes No No Yes Yes J (STND) Parkflyer
R6208SB 9 8 1 0 Yes - Hi-Speed/Normal Yes No No Yes Yes J (STND) Full-range
R6303SB 4 3 1 0 Yes - Hi-Speed/Normal, 7 Modes Yes No No Yes Yes J (STND) Full-range
R6303SBE 4 3 1 0 Yes - Hi-Speed/Normal, 7 Modes Yes No No No No J (STND) Parkflyer
R7003SB 4 3 1 to 2 1 Yes - 11 Modes No Yes (FASSTest) No Yes Yes J (STND) Full-range
R7008SB 9 8 1 1 Yes - 4 Modes No Yes (FASSTest) No Yes Yes J (STND) Full-range
R7006SB 6 6 1 1 Yes - 4 Modes No Yes (FASSTest) No Yes Yes J (STND) Full-range
R7018SB 21 18 1 1 Yes - FASSTest/FASST Multi, Hi-Speed/Normal No Yes (FASSTest) No Yes Yes J (STND) Full-range
R7014SB 15 14 1 1 Yes - SB/DG2, FASSTest/FASST Multi, Hi-Speed/Normal No Yes (FASSTest) No Yes Yes J (STND) Full-range

Model Number of Ports PWM Output SBUS Ports SBUS2 Ports FASST Telemetry S-FHSS High Speed High Voltage Connector Range
R614FS 5 4 0 0 Yes (C2) No No Yes Yes J (STND) Full-range
R603FS 4 3 0 0 Yes (C1) No No Yes Yes J (STND) Full-range
R603FF 4 3 0 0 Yes (C1) No No Yes Yes J (STND) Full-range
R304SB 5 4 0 1 No Yes (T-FHSS) No Yes Yes J (STND) Full-range
R304SB-E 5 4 0 1 No Yes (T-FHSS) No Yes Yes J (STND) Only for EP Car Models
R324SBS 5 4 0 1 No Yes (T-FHSS) No Yes Yes J (STND) Full-range
R334SBS 5 4 0 1 No Yes (T-FHSS) or (T-FHSS SR) No Yes Yes J (STND) Full-range
R334SBS-E 5 4 0 1 No Yes (T-FHSS) or (T-FHSS SR) No Yes Yes J (STND) Only for EP Car Models
R203GF 4 3 0 0 No No Yes Yes Yes J (STND) Full-range
R204GF-E 4 4 0 0 No No Yes Yes Yes J (STND) Only for EP Car Models
R2104GF 5 4 0 0 No No Yes Yes Yes J (STND) Full-range
R603GF 4 3 0 0 No No FHSS No Yes J (STND) Full-range
