Description
Attack 2DR Transmitter – 2-Channel Digital Proportional RC System
For Use with Surface Models (01004360-3) (01004359-3)
FEATURES
STEERING TRIM:
Steering neutral adjustments can be made by moving the steering trim to the left or right.
THROTTLE TRIM:
Throttle neutral adjustments can be made moving the throttle trim to the up or down.
SERVO REVERSING:
This function reverses the rotation direction of the steering and throttle servos.
CONTENTS
YOUR T2DR INCLUDES THE FOLLOWING COMPONENTS:
- -T2DR Transmitter
- -R162JE 27 MHz OR R162JE 75 MHz Receiver
- -2 x S3003 Servos
- -Switch
- -Battery Holder
- -Servo Mounting Hardware and Horns
TRANSMITTER SPECS
2 CHANNELS, AM TRANSMITTER
TRANSMITTER FREQUENCY:
27, 29, 40, 41, 72, or 75 MHz
MODULATION METHOD:
AM
POWER REQUIREMENT:
12 V (Penlight Battery X 8)
CURRENT DRAIN:
250 mA
RECEIVER SPECS
R162JE (Both 27 MHz and 75 MHz)
CHANNEL:
2ch AM
SIZE:
28.6 mm x 42.9 mm x 15.3 mm
1.13 in x 1.69 in x 0.60 in
WEIGHT:
14 g
0.49 oz
SERVO SPECS
S3003
SPEED:
0.23 sec/60°at 4.8V
0.19 sec/60° at 6.0V
TORQUE:
44.4 oz/in at 4.8V
56.9 oz/in at 6.0V
SIZE:
1.6 in x 0.8 in x 1.4 in
WEIGHT:
1.3 oz
